Overview
Sitrak’s G7 6×4 Tipper Truck is designed to meet the rigorous demands of the construction and mining industries. Equipped with a high torque 540HP engine and robust body construction, this dump truck delivers exceptional performance, durability, and operator comfort. Ideal for heavy-duty applications, the G7 6×4 Tipper Truck ensures efficiency and reliability in every job.
- Reliable German Technology 540hp engine with a high 2500 Nm torque
- 12 Speed ZF TraXon AMT gearbox
- Luxury spacious Cab with Top Cooler, ISRI Ventilated & heated seat, LED Lighting, and ZF Retarder as standard
- Differential locks and cross locks for when the going gets tough
- Alloy rim, air tank and fuel tank
- Air suspension to reduce tare weight
- ZF steering pump, Continental Color display, Voss connector, and JOST fifth wheel
- Fully compliant with Australia Design Rules
Features
The G7 6×4 Modern Ejector truck is packed with features designed to enhance performance and safety:
High Torque Engine
Powerful 540 HP engine provides a high 2,500 torque for heavy-duty tasks.
Safety Features
Includes a built-in crumple zone, EBS, ESC, EBL and ASR for enhanced safety.
Comfortable Drive
Air Suspension and a 12-gear AMT gearbox for a smoother ride and improved handling.
Versatile Tipping
Suitable for both spreading and bulk tipping and designed to work seamlessly with paving machines.
Operator Assistance
Equipped with electronic alarms to assist operators during ejector operations.
Luxury Cabin Interior
Designed for driver covert with a spacious cabin that includes top cooler, ventilated & heated seat and upgraded dash as standard.
Full Specifications
Discover the comprehensive technical details of the G7 6×4 Tipper truck, designed to deliver exceptional performance, safety, and reliability in every aspect of its construction and operation.
External Dimensions
- Length: 7,975m
- Width: 2,492mm
- Height:
- Unladen: 3,205mm
- Laden: 3,145mm
- Wheelbase: 4,300mm
- Wheel Track:
- Rear: 1,817mm
- Outer Rear: 2,450mm
- Ground Clearance:
- Front: 285mm
- Rear: 215mm
- Approach Angle: 15°
- Departure Angle: 20°
- Front Overhang: 1,475mm
Weights
- Gross Vehicle Mass (GVM): 25 tonnes
- Chassis mass:
- Front: 4.85t
- Rear: 3.57t
- Total: 8.42t
- Gross Combination Mass (GCM): 75 tonnes
Capability
- Maximum Speed: 110 km/h
- Minimum Turning Diameter: 16m
- Maximum Climb Gradient: 35%
- Fuel Tank Capacity: 600L
Cabin
- Model: C7-F
- Seating: 2
- Turning Radius: 3,640mm
Engine
- Model: 540 hp German Technology 13.54-50
- Displacement: 12.419L
- Power Rating: 397kW at 1,900rpm
- Maximum Torque: 2,500Nm at 1,050-1,350rpm
Clutch
- Model: CH430-25 diaphragm
- Operation Mode: Hydraulic with air
Frame
- Model: Trapezium frame
- Main Beam Cross-Section: 270x85x8mm
- Width of Frame Assembly:
- Front: 940mm
- Rear: 762mm
Transmission
- Model: ZF 12TX2621 TD
12-speed ZF TraXon AMT - 2-pedal operation with automatic and manual shift control
- Standard: Retarder and ZF Power Take-Off (PTO)
Electrics
- Circuit Type: Double, control positive pole
- Voltage: 24V
- Generator Power: 2.0kW
- Accumulator Voltage / Capacity: 2x12V / 180Ah
Steering Gear
- Model: Ball circul
- Ratio: 22.2 – 26.2
- Maximum Pressure of Pump: 18,300kPa
- Steering Way: Recirculating ball
Braking System
- Type: Wabco EBS/ESC/EBL/ASR
- Parking Brake: Spring stored energy air cut brake (Maxi)
- Auxiliary Braking: Air controlled exhaust brake and Retarder
- Front: 430mm Disc
- Rear: 375mm Disc
- Aluminium air reservoirs
Suspension
- Front: Non-independent (3 leaf parabolic)
- Rear: Hendrickson 8 air bag with ECAS to control ride
Rear Axle
- Model: MCY13 disc
- Capacity: 18.0 tonnes
- Ratios: 3.08 (Optional: 2.85, 3.08, 3.7, 4.11)
- Differential: Driver controlled differential locks
Front Axle
- Model: HF7 (Disc)
- Capacity: 7.0 tonnes
Extras
- Trailer brakes ABS to rear: Included
- Sunvisor, Side Skirts: Included
- Retarder: ZF Retarder
Why Choose the G7 6x4 Tipper?
Powerful Performance
Equipped with a high torque 540HP engine, delivering exceptional power for heavy-duty tasks.
Robust Construction
Features a durable MTE Hardox body, designed to withstand demanding environments.
Advanced Safety
Includes built-in crumple zone, ABS, and EBS for enhanced safety on the job.
Superior Comfort
Large, roomy high-top cab ensures maximum operator comfort during long shifts.
Efficient Suspension
Air suspension system provides a smoother ride and better handling.
Versatile Capability
Differential locks, cross locks, and Voith retarder offer superior traction and braking performance in tough conditions.
