Meet Sitrak's G7 10x4 Model

Overview

Sitrak’s G7 10X4 Tipper is designed to meet the rigorous demands of construction and urban transportation. With a robust build, high torque engine, and a range of features that enhance safety and drivability, the G7 10×4 Tipper is the ideal dump truck for a variety of applications.

  • Reliable German Technology 540hp engine with a high 2500 Nm torque
  • 12 Speed ZF TraXon AMT gearbox
  • Luxury spacious Cab with Top Cooler, ISRI Ventilated & heated seat, LED Lighting, and ZF Retarder as standard
  • Differential locks and cross locks for when the going gets tough
  • Alloy rim, air tank and fuel tank
  • Air suspension to reduce tare weight
  • ZF steering pump, Continental Color display, Voss connector, and JOST fifth wheel
  • Fully compliant with Australia Design Rules

Features

The Sitrak’s G7 10X4 Tipper is packed with features designed to enhance performance and safety:

High Torque Engine

Powerful 540 HP engine provides a high 2,500 torque for heavy-duty tasks.

Safety Features

Includes a built-in crumple zone, EBS, ESC, EBL and ASR for enhanced safety.

Comfortable Drive

Air Suspension and a 12-gear AMT gearbox for a smoother ride and improved handling.

Mezzanine Floor Capability

The truck offers the flexibility of a mezzanine floor, optimizing space and load management.

Operator Assistance

Equipped with electronic alarms to assist operators during ejector operations.

Luxury Cabin Interior

Designed for driver covert with a spacious cabin that includes top cooler, ventilated & heated seat and upgraded dash as standard.

Full Specifications

The G7 8×4 Tipper Truck is engineered for superior performance and reliability. Below are the detailed specifications that ensure it meets the rigorous demands of various tipping applications

External Dimensions

  • Height:
    • Unladen: 3,272mm
    • Laden: 3,212mm
  • Wheelbase: 6,750mm
  • Wheel Track:
    • Rear: 1,850mm
    • Outer Rear: 2,480mm
  • Ground Clearance:
    • Front: 285mm
    • Rear: 215mm
  • Approach Angle: 15°
  • Departure Angle: 46°
  • Front Overhang: 1,475mm

Weights

  • Gross Vehicle Mass (GVM): 31 tonnes
  • Chassis mass:
    • Front: 6.15t
    • Rear: 3.02t
    • Total: 9.17t

Capability

  • Maximum Speed: 100 km/h
  • Minimum Turning Diameter: 16m
  • Maximum Climb Gradient: 35%
  • Fuel Tank Capacity: 600L

Cabin

  • Model: C7-F
  • Seating: 2
  • Turning Radius: 3,640mm
  • Hardox Bin
  • Scale side ladder
  • Lift axle
  • Two Way Gate

Engine

  • Model: 540 hp German Technology 13.54-50
  • Displacement: 12.419L
  • Power Rating: 397kW at 1,900rpm
  • Maximum Torque: 2,500Nm at 1,050-1,350rpm

Clutch

  • Model: CH430-25 diaphragm
  • Operation Mode: Hydraulic with air

Frame

  • Model: Trapezium frame
  • Main Beam Cross-Section: 270x85x8mm
  • Width of Frame Assembly:
    • Front: 940mm
    • Rear: 762mm

Transmission

  • Model: ZF 12TX2621 TD
    12-speed ZF TraXon AMT
  • 2-pedal operation with automatic and manual shift control
  • Standard: Retarder and ZF Power Take-Off (PTO)

Electrics

  • Circuit Type: Double, control positive pole
  • Voltage: 24V
  • Generator Power: 2.0kW
  • Accumulator Voltage / Capacity: 2x12V / 180Ah

Steering Gear

  • Model: Ball circul
  • Ratio: 22.2 – 26.2
  • Maximum Pressure of Pump: 18,300kPa
  • Steering Way: Recirculating ball

Braking System

  • Type: Wabco EBS/ESC/EBL/ASR
  • Parking Brake: Spring stored energy air cut brake (Maxi)
  • Auxiliary Braking: Air controlled exhaust brake and Retarder
  • Front: 430mm Disc
  • Rear: 375mm Disc
  • Aluminium air reservoirs

Suspension

  • Front: Non-independent (3 leaf parabolic)
  • Rear: Hendrickson 8 air bag with ECAS to control ride

Rear Axle

  • Model: MCY13 disc
  • Capacity: 18.0 tonnes
  • Ratios: 3.08 (Optional: 2.85, 3.08, 3.7, 4.11)
  • Differential: Driver controlled differential locks

Front Axle

  • Model: HF7 (Disc)
  • Capacity: 10 tonnes

Extras

  • Trailer brakes ABS to rear:  Included
  • Sunvisor, Side Skirts: Included
  • Retarder: ZF Retarder

Why Choose the G7 10x4 Tipper?

Robust Build

Constructed with durable Hardox steel for long-lasting performance in demanding environments.

High Torque Engine

330HP engine delivering exceptional power and efficiency for various tipping applications.

Advanced Safety

Equipped with ABS, EBS, and a built-in crumple zone for enhanced safety.

Efficient Transmission

Synchro ZF 9 Speed gearbox ensures smooth and reliable drivability.

Versatile Design

Flexible configurations to meet diverse transportation needs, from construction sites to urban settings.

Comprehensive Support

Backed by excellent customer service and support for all your operational requirements.
